PT2Ex Cortex-M0



    PT2Ex Cortex-M0


    選擇指南

    Part No.PT2E01-Q6LIPT2E01-K6OIPT2E01MA-Q6LI
    Frequency(MHz)
    80
    80
    80
    Flash (KB)
    64
    64
    64
    SRAM (KB)

    8

    8

    8
    I/O
    43
    27
    27
    DMA (ch)
    1(6)
    1(6)
    1(6)
    CALC/CRC
    1/1
    1/1
    1/1
    PWM ch.
    28
    23
    22 ①
    E16C6T
    1
    1
    1
    A16C4T
    2
    2
    2
    A32C2T
    2
    2
    2
    B16T
    1
    1
    1
    SysTick
    1
    1
    1
    IWDT/WWDT
    1/1
    1/1
    1/1
    I²C
    1
    1
    1
    SPI
    2
    2
    2
    I²S
    -
    -
    -
    UART
    2
    2
    2
    SAR-ADC
    1
    1
    1
    SAR-ADC ch. (ext./int.)
    16/4
    11/4
    14/4
    OPAMP/CMP
    1/1
    1/1
    1/1
    Operation Voltage (V)
    VDDH: 2 - 5.5V
    VDDA: 2.4 - 5.5V
    VDDH: 2 - 5.5V
    VDDA: 2.4 - 5.5V
    VDDH: 2 - 5.5V
    VDDA: 2.4 - 5.5V
    Other Additional Features / Application
    -
    -
    -
    AEC-Q100
    -
    -
    -
    Gate driver operating voltage（VDRV_PWR）
    -
    -
    10 - 20V
    Package
    LQFP48
    QFN32
     LQFP48

    ① When calculating the number of PWM channels, E16C4T_CH1 to E16C4T_CH3 used for SIP and their corresponding complementary outputs are not taken into account.
    • PT2E01
    • PT2E01MA

    應用領域
